Factory Sprayer Irrigation Liquid Transfer 12V Self Priming 30L/min DC Pump
Whaleflo Diaphram Adblue pumps and accessories
suitable for use other liquids from the urea manufacturing process. They are diaphragm pumps with a by-pass Which is designed to dispense products called Ad Blue, AUS32 or water, and also widely used in chemical equipment, agriculture (lawn and garden), carpet cleaning, floor/ground cleaning, and water treatment equipment.
Suitable for IBC transmission systems, permanent magnet pumps work continuously.
Specification
Model Number: HV-30A
Body Materials: Aluminum
Voltage: DC 12V
Current: 15.0A
Pressure off: 40PSI
Frequency: 50/60Hz
Flow(Liters/Min):30-35L
Power: Electric
Pressure Switch: Build in
Speed: 2800rpm
Liquid of Transfer: AdBlue, AUS 32, Water etc.
IP55 Protection, CE
Features&Highlights
Whaleflo Diaphragm Adblue Pump material: aluminum alloy, durable, corrosion resistant, high quality
Permanent magnets and continuous load: maintain a good motor to maintain a stable temperature of the 2m wire plug of the pump body
Whaleflo Self-priming water pump: can be located above the water tank and dry in a short time (up to 20 minutes) without damage
Easy to operate: on/off switch, built-in pressure switch for automatic start or stop when the faucet is opened and closed
Application: Suitable for applications where liquids are transferred from one location to another, such as AdBlue, AUS32 or water etc, spraying, recycling, irrigation and distribution
Note:They must not pump gasoline, chemicals, high viscosity liquids, solvents, etc.
|
Item Code |
Volt | Flow Rate(L/min) | Pressure (PSI) | Amps(A) | Speed(rpm) |
| HV-30A | 12V DC | 30-35 | 40 | 15.0 | 2800 |
| HV-30B | 24V DC | 30-35 | 40 | 7.5 | 2800 |
| HV-30S | 115V AC | 30-35 | 40 | 4.0 | 3400 |
| HV-30M | 230V AC | 30-35 | 40 | 1.5 | 2900 |
