Whaleflo Stainless Wort Pump Factory Direct MP-15RM OEM Color
The small batch brewers dream pump! This Brewing Pump MP-15R with Stainless Steel head is perfect for recirculating and transferring wort.
1/2"BSP thread or 1/2" NPT Thread With Stainless Steel Head
Max Capacity: 16/19 L/min .
Rated Capacity: 8/12 L/min .
Max Head :2.7/3.4 Meter .
Rated Head:1.5 Meter .
Feature: 1. This pump is full-sealed structure, avoids liquid leakage.
2. High working temperature, the maximum working temperature is 140℃
3. Allow long-time working.
4. This pump is not a self-priming pump, it cannot suction itself. When starting to run the pump, the pump head must be filled with liquid, so that the impeller will work normally to transfer. Do not empty transport. It is forbidden to run dry, running dry will cause the motor and impeller damaged.
| Type | 220V EU/AU Plug, 110V US Plug | ||
| Output | 10W | Frequency | 50/60Hz |
| Rated Capacity | 8/12 L/min | Max.Capacity | 16/19 L/min |
| Rated Head | 1.5Meter | Max.Head | 2.7/3.4Meter |
| Poles | 2 | Power Consumption | 22/25W |
| Speed | 2600/3000 rpm | Rating | Cont. |
| Capacitor | 1uF/ 500V AC | Rated Current | 150mA |
| Feauture | Magnetic Pump 15R, stainless Head 1/2”NPT thread,With Stainless Steel Head | ||
| Insulation | Class B | Thread Interface | |
| Temperature | Out-inlet(inch) | Tube(mm) | |
| 0~140℃ (32℉~284℉) | 1/2''BSP |
