Whaleflo 110V 220V Self Priming AC Diesel Fuel Transfer Pump 80Lpm

ac self priming diesel kerosene pump
  • Product Origin:

    China
  • Brand:

    Whaleflo
  • Item NO.:

    YB-80
  • Shipping Port:

    Xaimen,Shanghai,Shenzhen,Ningbo
  • Lead Time:

    5-25 working days
  • Payment:

    T/T,Paypal,Western Union Transfer,

Hot Products

Products Description

Whaleflo 110V 220V Self Priming AC Diesel Fuel Transfer Pump 80Lpm

AC Diesel Fuel Transfer Pump Descritption

Product name
Car Electric oil transfer Pump * single suction
Voltage
AC 220V ±10%50Hz
AC 110V±10% 60Hz
OEM
Acceptable
By pass valve
Yes
Power
750W
Max Suction
5m
Type
vane pump self priming
Weight
8.5Kg
Flow
70-80L/min
Strainer
Yes

This high efficient self-priming oil extractor pump is an ideal equipment for quick and clean oil-changes,

and it can pump various fluids and kerosene oils.This process is very simple and you can often do it by yourself to ensure your engine runs smoothly. Why notbring this nice oil extractor pump home?
AC Diesel Fuel Transfer Pump Feature:

1. Oil extractor pump with 750W for effective and powerful operation.
2. Ideal equipment for quick and clean oil-changes.

3. Easy to install.no specialized tools needed.
5.Impeller suction single suction.More powerful.
6. Ideal for industrial,boat, vans, cars, quads and other Vehicles, fit to use with diesel, kerosene, suitable

for extracting oil, diesel

1. For fueling diesel oil, kerosene, not for gasoline. Heavy fuel oil transfer pump

2. Cast iron casing, rotary vane pump, steel rotor.

3. Bypass valve built in.

4. Built in filter, easily accessible for cleaning.

5. Self priming: Yes

6. Induction motor with aluminum casing, IP54

7. Continuous working principle

8. Applicable in transferring oil from barrels, fueling machines in construction sites, boat, agriculture.

Inlet&out Size: 1"

Flow Rate: 80L/min

Power: 750W

Suction:3-5M

Head: 5-10m

Grade of protection : IP54

Product introduction:
This self-priming pump only for pumping Diesel or Kerosene,do not pump low ignition oil like Gasoline, Liquefied Petroleum Gas or Alcohol as well as high viscous oil like Engine Oil.


Technical Parameters:

Model

JYB40

YB60

YB80

Flow Rate

(20-40)L/min

(20-60)L/min

(50-80)L/min

Rated Voltage

AC220V

AC 220V or 110V

AC 220V or 110V

Power

120W

375W

550W

Pressure

0.16-0.18Mpa; 1.6-1.8bar;
23-26psi

0.18-0.20Mpa; 1.8-2.0bar;
26-29psi;

Suction Lift

3m

3-5m

Head Lift

6m

5-10m

In-out

In BSPT3/4",
Out BSPT3/4"

In BSPT1", Out BSPT1"


Note:

1. The filter must be cleaned regularly.
2. The pumping fuel's ignition should not exceed 55 ºC.

3. Do not empty spin.

whaleflo diesel pump

whaleflo diesel pump kit
