Whaleflo 15W 1.5LPM Low Noise Booster Self-Priming Food Grade Diaphragm Pump Factory
Whaleflo Food Grade Pump Basic information
Theory:diaphragm pump electric drive
Inlet/outlet:7.5mm
Liquid temp:max 70℃
Whaleflo high-quality DC micro diaphragm pump.
Widely used in water purification and water treatment equipment.
Safe food-grade materials, healthy, environmentally friendly.
Can be used for the transfer of various alcohols, liquid medicines, drinking water.
TECHNICAL DATE
|
Model |
Volt |
Power |
Protect valve |
Max.working pressure |
Flow rate |
Amps |
Suction |
Lift |
|
FLO-0342 |
12 |
15W |
Pressure switch |
4bar/58psi |
1.5LPM |
2.5A |
1.2M |
40m |
|
FLO-0442 |
12 | 60W | Pressure switch | 0.8Mpa-0.55Mpa | 5LPM | 5A | 1.2M | 40M |
|
Pump head material |
PC/PP/TPV(FDA)/SS 304 |
Pump body |
Pure copper motor/PC/PVC,etc. |
|||||
